yxpolyer ABS-SP40 Black 1.75mm 1kg

yxpolyer ABS-SP40 Black 1.75mm 1kg

5,400 kr

yxpolyer ABS-SP40 is a modified ABS filament engineered for low warping and improved layer adhesion, delivering tensile strength around 47 MPa with a heat deflection temperature of 80°C @ 0.45 MPa. The reduced warpage makes it significantly more forgiving to print than standard ABS, especially for larger parts. Suitable for power tool housings, automotive interior parts, display stands, and other impact-resistant structural components. Requires an enclosure.

📊 Technical Specifications

Nozzle Temperature 220-260 °C
Bed Temperature 80-100 °C
Print Speed 30-200 mm/s *
Part Cooling Fan 0 % *
Max Volumetric Speed 14 mm³/s *
Drying Temperature 80 °C *
Drying Time 6 hours *
Enclosure Required Yes *
Tensile Strength (Yield, XY) 47 MPa
Tensile Strength (Yield, Z) 35.2 MPa *
Tensile Strength (Break, XY) 40 MPa *
Tensile Strength (Break, Z) 30 MPa *
Tensile Modulus (XY) 2300 MPa *
Tensile Modulus (Z) 1840 MPa *
Elongation at Break 15 %
Flexural Strength (XY) 70 MPa
Flexural Strength (Z) 42 MPa
Flexural Modulus (XY) 2300 MPa
Flexural Modulus (Z) 1556 MPa
Impact Strength (Izod) 280 J/m *
Impact Strength (Unnotched, XY) 28 kJ/m²
Impact Strength (Unnotched, Z) 10 kJ/m²
Heat Deflection (0.45 MPa) 80 °C
Heat Deflection (1.8 MPa) 65 °C *
Glass Transition (Tg) 100 °C *
Melting Point 95-135 °C *
Density 1.0 g/cm³
Hardness (Shore A) 53.6 *
Hardness (Shore D) 52.7 *
Hardness (Rockwell R) 110 *
Continuous Service Temp 70 °C *
Light Transmittance 5 % *
Dielectric Strength 19 kV/mm *
Impact Strength (Charpy) 20 kJ/m² *
Elongation at Yield 3 % *
Mold Shrinkage 0-0 % *
Water Absorption (24h) 0.2 % *
Flammability Rating HB *
Bed Adhesion ABS Adhesive *

* Estimated values based on material family characteristics
