yxpolyer conductive ABS is a specialty ABS filament formulated with conductive additives to provide reliable static dissipation for ESD-safe applications. Surface resistivity in the 10³ Ω/sq range makes it suitable for electronics manufacturing fixtures, PCB handling tools, ESD trays, and EMI shielding enclosures. Maintains printability similar to standard ABS. Requires an enclosure.

📊 Technical Specifications

Nozzle Temperature 220-260 °C
Bed Temperature 100-110 °C
Print Speed 20-80 mm/s *
Part Cooling Fan 0 % *
Max Volumetric Speed 10 mm³/s *
Drying Temperature 80 °C *
Drying Time 6 hours *
Enclosure Required Yes *
Tensile Strength (Yield, XY) 30 MPa
Tensile Strength (Yield, Z) 22.5 MPa *
Tensile Strength (Break, XY) 30 MPa
Tensile Strength (Break, Z) 22.5 MPa *
Tensile Modulus (XY) 1125 MPa *
Tensile Modulus (Z) 900 MPa *
Elongation at Break 3 %
Flexural Strength (XY) 27 MPa
Flexural Strength (Z) 8 MPa
Flexural Modulus (XY) 1125 MPa
Flexural Modulus (Z) 957 MPa
Impact Strength (Izod) 95 J/m *
Impact Strength (Unnotched, XY) 26 kJ/m²
Impact Strength (Unnotched, Z) 2 kJ/m²
Heat Deflection (0.45 MPa) 87 °C
Heat Deflection (1.8 MPa) 72 °C *
Glass Transition (Tg) 95 °C *
Melting Point 95-135 °C *
Density 1.1 g/cm³
Hardness (Shore A) 53.6 *
Hardness (Shore D) 52.7 *
Hardness (Rockwell R) 108 *
Continuous Service Temp 75 °C *
Light Transmittance 5 % *
Dielectric Strength 19 kV/mm *
Impact Strength (Charpy) 20 kJ/m² *
Elongation at Yield 2 % *
Mold Shrinkage 0-0 % *
Water Absorption (24h) 0.3 % *
Flammability Rating HB *
Bed Adhesion ABS Adhesive *

* Estimated values based on material family characteristics
