Yasin PA12 Black 1.75mm 1kg

Yasin PA12 Black 1.75mm 1kg

6.540 kr
Skip to product information
Yasin PA12 Black 1.75mm 1kg
  • Yasin PA12 Black 1.75mm 1kg
  • Yasin PA12 Black 1.75mm 1kg
Yasin PA12 Black 1.75mm 1kg

Yasin PA12 Black 1.75mm 1kg

6.540 kr

Nylon 12 (PA12) offers similar engineering properties to PA6 but with significantly lower moisture absorption and reduced warping. It provides excellent chemical resistance flexibility and fatigue resistance making it ideal for living hinges and repeated-use parts. Easier to print than PA6 but still requires drying and enclosed printer.

Note: For best print quality, we recommend drying before use.

📊 Technical Specifications

Nozzle Temperature 255-275 °C *
Bed Temperature 90-110 °C *
Print Speed 40-60 mm/s *
Part Cooling Fan 0-20 % *
Max Volumetric Speed 14.4 mm³/s *
Drying Temperature 70-80°C *
Drying Time 4 hours *
Enclosure Required Yes *
Tensile Strength (Yield, XY) 70 MPa
Tensile Strength (Yield, Z) 42 MPa *
Tensile Strength (Break, XY) 64.4 MPa *
Tensile Strength (Break, Z) 38.6 MPa *
Tensile Modulus (XY) 2030 MPa
Tensile Modulus (Z) 1319.5 MPa *
Elongation at Break 50 %
Flexural Strength (XY) 87 MPa *
Flexural Strength (Z) 60.9 MPa *
Flexural Modulus (XY) 1928.5 MPa *
Flexural Modulus (Z) 1311.4 MPa *
Impact Strength (Izod) 40.0 J/m *
Impact Strength (Unnotched, XY) 3.4 kJ/m² *
Impact Strength (Unnotched, Z) 1.7 kJ/m² *
Heat Deflection (0.45 MPa) 110 °C
Heat Deflection (1.8 MPa) 95 °C
Glass Transition (Tg) 115 °C
Melting Point 105-145 °C *
Density 1.0 g/cm³
Hardness (Shore A) 54 *
Hardness (Shore D) 115 *
Hardness (Rockwell R) 115 *
Continuous Service Temp 85 °C *
Light Transmittance 80 %
Dielectric Strength 50 kV/mm
Impact Strength (Charpy) 0.8 kJ/m²
Elongation at Yield 8 %
Mold Shrinkage 0-1 %
Water Absorption (24h) 0.9 % *
Flammability Rating V-2
Bed Adhesion PVA Glue *

* Estimated values based on material family characteristics
